Ametco's custom Security Gate Systems utilize a tube frame design with steel, aluminum or stainless steel infill panels and louvers. You can choose from a variety of panel styles, including numerous sizes of square or rectangular mesh patterns, or louvers. The tube frame can also be manufactured in steel, aluminum or stainless steel.

Integrated custom gate systems are available in swing gates, v-wheel roller gates or monorail track cantilever gates. These gate systems are designed to work efficiently and trouble-free in virtually any setting.

Our engineering department will work with you to design a gate that is functional and fits aesthetically in all surroundings. Ametco's standard security gate systems are available in many sizes and in a variety of styles. Custom fabrication services are available to complete even the most complex metal structures.

Ametco's custom Security Gate systems are manufactured using an exclusive electro-forged welding process that provides complete penetration of the cross member, and most have a hot-dip galvanized finish with a polyester powder coating that provides the best corrosion protection available.

Ametco's gate systems:
  • Are protected from the elements
  • Have greater rigidity
  • Eliminate most maintenance
  • Handle exposure to the elements without crazing or fading
  • Are available in 15 color choices
