Park Design

Park Design  ...welded wire 2" x 8" mesh with 3/16" vertical and two 1/4" horizontal wires

The welded wire fence, Park Design is similar in design to Fiesta Design and Guardian Designwith the same mesh only lighter wire diameter. The post and attachment  is the same as Guardian Designwhich mounts to the post with K-fasteners.

Security Need:      Basic-to-Medium

Features: The Park Design is the most economical of the Ametco® Welded Wire fencing line and still provides security for your perimeter fencing requirements. Manufactured with Ametco’s high tensile wire that is weld then hot dip galvanized before powder coating. This system provides the Park Design with the best corrosion protection in the industry.

In short: The Park Design offers economical perimeter protection.

Technical data: 2" x 8" mesh with 3/16" vertical wire and two 1/4" horizontal wires. Panel width 98-1/4" and heights of 4, 6 and 8 feet, special 2" square tube post with  K-fasteners on 99-1/4" post centers.

View Ametco's 20 Year Warranty

Bookmark and Share
CAD Drawings
Please click on thumbnail below to load a larger image:
Park Design Park Design
Downloads
6 page PDF; Highlights the 4 Ametco Welded Wire Fence designs
8 page PDF: Brochure features Swing, Cantilever, V-Wheel Roller security gates in aluminum, galvanized steel and stainless steel. Panels styles, CAD drawings and color options are covered.
8-page PDF: Highlights the numerous panel designs, configurations, CAD drawings and installation of Ametco's fence products.
 Master Spec for Welded Wire Fencing

Panel Designs
Welded wire 2" x 8" mesh, 3/16" dia. wire with folds for strengthening
Welded wire with 2" x 8" mesh, 1/4" vertical wire and two 5/16" horizontal wires
Welded wire 2" x 8" mesh, 1/4" vertical and two 5/16" horizontal wires.
Welded wire 2" x 8" mesh with 3/16" vertical and two 1/4" horizontal wires
