Style 104-45 Sunshades


Style 104-45  Aluminum Sunshades    4" x 1/2" Aluminum Extrusions on 4-7/16" Centers

Ametco's Style 104-45  Aluminum Sunshades are manufactured to order from 4" x 1/2" aluminum extrusions. Ametco's extruded aluminum Sunshades provide the best wieght to strength ratio. The extruded tube design has a minimum top surface area to hold the dirt and snow buildup to a minimum. Stlye 104-45 Sunshades are designed with the depth and spacing of the tube required to achieve 60 degrees incident angle of Sunshade. Ametco® certifies that its sunshade system is free from defects in material and workmanship. The Sunshades are powder coated for lasting beauty. The polyester coated aluminum is guaranteed not to crack, peel or blister for a period of 20 years. See Ametco's 20 year warranty.

Other styles include:

Style 102-45  Aluminum Sunshades  2" x 1/2" aluminum extrusion on 2-3/16" centers

Style 102-90  Aluminum Sunshades   2" x 1/2" aluminum extrusion on 1-3/8" centers

Style 104-90  Aluminum Sunshades  4" x 1/2" aluminum extrusions on 2-1/2" Centers
Made In USA

View Ametco's 20 Year Warranty

Bookmark and Share
CAD Drawings
Please click on thumbnail below to load a larger image:
Sunshade Hardware - Intermediate Outrigger for Curtain Wall Mounting Sunshade Hardware - Intermediate Outrigger for Curtain Wall Mounting
Sunshade Hardware - Intermediate Outrigger for Structural Column or Concrete Wall Sunshade Hardware - Intermediate Outrigger for Structural Column or Concrete Wall
Suspended Rod Connection Suspended Rod Connection
Support Rod Connection Support Rod Connection
Channel Frame for Bar Grille & Fixed Louver Support Rod COnnection Channel Frame for Bar Grille & Fixed Louver Support Rod COnnection
SUNSHADE 104-45 SUNSHADE 104-45
Downloads
4-page PDF of bar grille, extruded aluminum, louver and perforated sunshades including CAD drawings and photos.
 Master Spec for metal Sunshades

Panel Designs
2" x 1/2" tube on 2-3/16" Centers
2" x 1/2" aluminum extrusion on 1-3/8" Centers
4" x 1/2" Aluminum Extrusions on 4-7/16" Centers
4" x 1/2" Aluminum Extrusions on 2-1/2" Centers
