Eclipse® Design …aluminum, steel and stainless steel louvers allowing 80% direct visual screening
Specify: Resistance welded steel, extruded Aluminum or Stainless Steel Eclipse® design has formed or extruded inclined main bars on 2-1/16" centers. Cross bars are on centers up to 18". All are polyester powder coated.
Eclipse® Aluminum is a 6063 extrusions weighing 1.3 lbs. per square foot.
Eclipse® Stainless Steel is type 304 stainless weighing 2.8 lbs. per square foot.
Eclipse® Steel is is hot dip galvanized to ASTM 123.
Ametco® louver designs are polyester powder coated to any of Ametco’s 15 standard colors. If your louver requirement is for widths from 1 foot to 500 feet, call Ametco® Mfg. Corp. and have one of our sales engineers work with you.
Eclipse® Aluminum - 80% Direct Visual Screening
