Downloads
Many of Ametco's architectural products can help builders qualify for LEED green building credits.
AMETCO'S FENCE PRODUCTS, GATE PRODUCTS RAILINGS, SUNSHADES, PERFORATED METAL
8 page PDF: Brochure features Swing, Cantilever, V-Wheel Roller security gates in aluminum, galvanized steel and stainless steel. Panels styles, CAD drawings and color options are covered.
8-page PDF: Highlights the numerous panel designs, configurations, CAD drawings and installation of Ametco's fence products.
8-Page PDF: Describes the 11 types of aluminum fencing systems.
Master Spec for extruded aluminum tube fence
|
|
Panel Designs
4" vertical or horizontal tubes with 4" opening weighing 1.75# per sq. ft.
Two, three or four - 4" horizontal rails on posts
2" vertical or horizontal tubes with 1" to 4" spacing. With 1" opening the Venus Design weight is 1.75#
4" and 2" x 1/2" vertical or horizontal tubes with 1" to 4" opening 1" spacing weight is 2# per sq. ft.
Apollo Design with 1/2" x 2" extruded aluminum tube open mesh aluminum fencing. Tube is on 2" centers and is 2.75 lbs per sq. ft.
Galaxy Design with 1/2" x 2" aluminum extrusion on 3-1/2" centers. wt. 1.75 lbs per sq. ft.
|
