Bar Grating

Bar grating is still the best choice for most heavy traffic, platforms and stair applications. Ametco® stocks a wide assortment of "close" mesh and "square" mesh grating ready for immediate delivery. We can even take your plan's dimensions and cut the grating to meet your exact requirements.

Stock Panels
Our ready-to-ship inventory includes standard panel sizes of 36" x 288" and 24" x 288". Standard bar sizes are 3/4" to 2-1/2" by 1/8" and 3/16" wide.

Fabricating Services
Manufacturing your custom designed bar grate platform is no problem. Simply submit an approved dimensional drawing to our sales department for a free estimate. Once fabricated, we lay out the entire platform on our plant floor and check the dimensions and obstructions against the original drawings for accuracy.

Fastners
(Zinc Coated Steel)


Model GG
For Grating Attachment to structural shapes. Available in galvanized or stainless steel


DF-2 Special 10-11GA
For removable panels. Clips for 19-W bearing bar spacing in stock. (Stud bolt, washer & nut supplied by others)

Track-Weld Positive
fastening method - grating is welded to supporting steel.



Choose a link for more bar grating information:

View Ametco's 20 Year Warranty
